Try Zone Heating and Cooling for Home Comfort

Family members may complain that some rooms in your house are too hot or cold, but it’s likely there’s not a home in the entire country that has even temperatures throughout all the rooms. Actually, depending upon the activity level in each room, a range of temperatures may be more comfortable for the whole family, since some people simply prefer to have it warmer or cooler.

There are many factors, such as the length of ductwork, bends, orientation to the sun, and the number of windows and exterior walls that impact room air temperature. What you keep in a room is also a factor—for example, if you have a large TV in a small room, it can raise the temperature.

A single furnace or heat pump is a common system in many homes. If you set the thermostat to keep the chilliest room warm, it causes many of the other rooms to become too warm. A warmer house loses more heat and forces the heating system to work harder. According to the U.S. Department of Energy, for each degree the thermostat is set lower for an eight-hour period, heating bills can be reduced by up to 1 percent.

Understanding Zone Control Systems
Installing an automatic zone control system is the best and most energy-efficient way to control individual room temperatures. This type of system adjusts special duct dampers, based upon both actual and desired room temperatures.

Many homes have access to only main ducts that branch out to individual rooms. In this case, a zone system will control the temperatures in each room grouping, such as all the bedrooms, kitchen/dining areas, and the living room. While it is optimum to control each room independently, having just three or four zones is adequate for comfort and energy savings.
A programmable thermostat is mounted in each room or grouping to control the motorized duct damper leading to it. If the room is too warm in winter, the damper partially closes. For example, a zone thermostat may continuously readjust the damper position as the intensity of the sun shining through a window changes throughout the day.

Most of the energy savings with an automatic zoning system is gained because each room temperature can be varied throughout the day. There is no need to keep the bedrooms toasty warm during the day, or the living room warm overnight. The programmable thermostats are designed to bring room temperatures back up without having the backup resistance elements come on.

There are various zoning damper designs, from a simple flat damper unit to bladders that inflate with air to close off the ducts. They all function equally well. With the many new thermostats and use-control electronics, adding a zoning system requires professional installation, so it’s wise to consult a qualified technician for help in designing the best system for your needs.

Companies offering zoning systems include Aprilaire (800-334-6011; aprilaire.com); Arzel Zoning Technology (800-611-8312; arzel.com); Durodyne (800-899-3876;
durodyne.com); EWC Controls (800-446-3110; ewccontrols.com); and Zonex Systems (800-228-2966; zonexsystems.com).
